Multi-lane Vertical Form Fill Seal Machine (Liquid)
Mechanical Features
Suit to liquid: Mouthwash / Shampoo / Cream / Oil / Sauce / Jell / Paste
The packaging machine can automatically complete bag-making, printing, metering filling, back sealing, pressing waterproof lines, sealing, easy-tear notch cutting, and round corner punching. The touchscreen allows direct setting of bag length and temperature segments, as well as product formula memory function.
With servo film pulling and servo filling systems, it ensures process stability and product accuracy. The design includes a single-channel micro-dosing adjustment mechanism for adjusting the filling quantity in a single channel.
Specifications
| Model | EZ-280BY (280, 560, 840 models) |
|---|---|
| Film Material | OPP/CPP, OPP/CE, MST/PE, PET/PE |
| Bag Type | Back seal, three-side seal, four-side seal, decorative bag |
| Film Roll Outer Diameter | 160–280 mm |
| Bag Width | 17–65 mm |
| Bag Length | 50～150 mm |
| Output (per lane) | 20–30 bags/min/lane |
| Air Pressure | 8 kg/cm²，200 L/min |
| Power Supply | AC 220V, 1 ph, 60 Hz, 3.5 kW |
| Net Weight | 500-1000 kgs |
| Machine Dimensions | 1,600 (L) * 2,100 (W) * 2,600 (H) mm |
| Filling System | Piston, Magnetic, Peristaltic, Ceramic, Sine. |
